HEAVY EQUIPMENT

SKIDSTEER LOADER - JCB 330


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

4 Hour: $225.00

Daily: $225.00

Weekly: $1,012.50

Monthly: $3,487.50

Quantity: for a period of
4 hour(s) day(s) week(s) month(s)

Additional Information

FUEL CONSUMPTION IS BILLED ON RETURN OF THE UNIT @ $5.00 PER METER HOUR USED.
Dimensions
Length With Bucket 12.41ft in
Width Over Tires 5.91ft in
E
Ground Clearance
9.85in
C
Height To Top Of Cab
6.86ft in
D
Wheelbase
4.11ft in
Clearance At Max Lift And Dump 8.08ft in
Reach At Max Lift And Dump 35.44in
Turning Radius From Center - Inc Bucket 86.62in
Turning Radius From Center - Machine Rear 69.3in
Loadover Height 9514.44ft in
Dig Depth 393.71in
Dump Angle 42degrees
Dump Height 7.55ft in
Angle Of Departure 29degrees
Pin Height 10498.69ft in
Rollback - Ground Level 30degrees
Specifications
Tyres:Standard 12 x 16.5 - 10 PR Xtra Wall Off Road
Fuel Diesel
Starter Motor 4.2 KW
Battery12 V
Engine Oil Service Interval: 500 hours
Engine Make; 2257
Engine Model
EcoMAX TCAE-55
Gross Power
74hp
Cooling System
Liquid
Power Measured @
2400rpm
Max Torque
295.1lb ft
Torque Measured @
1200rpm
Aspiration
Turbo
Displacement
268cu in
Operational
Operational Weight
9288.1lb
Fuel Capacity
27.3gal
Cooling System Fluid Capacity
4.1gal
Engine Oil Fluid Capacity
4gal
Hydraulic System Fluid Capacity
14.6gal
Max Speed
12.4mph
Chain Box Fluid Capacity - Each Side
6.1gal
Operating Speed
6.8mph
Tire Size
12 x 16.5
Operating Voltage
12V
Alternator Supplied Amperage
95amps
Transmission
Model
Two Speed
Travel Speed
12.5mph
Loader
Loader Lift Capacity With Bucket
6056.1lb
Breakout Force
6543.4lb
Operating Load Rating
3000lb
Tipping Angle
6369.2degrees
Bucket Capacity
0.6yd3
Bucket Width
74.9in
Hydraulic
Pump Flow Capacity
23.8gal/min
Relief Valve Pressure
3335psi

Also check the following item(s) related to the above:

* All prices are in CI$ and are subject to change and other fees may not be shown in the above price lists. Rates are rental only. Other charges may apply for fuel, cleaning, delivery, setup, etc. Some event equipment item photos show add-on decor items by others. Please check with us if in doubt on what is included.
